Vacuum Brazed Diamond Cutting Dics - Vaccum Brazed Saw Blades

Application: Can be used for the cutting of marble, granite, reinforced concrete, cobble stone, foundry etc. Besides, It can also be used for cutting organic materials with high strength and high flexibility.

Features: Strong combination between diamond and the metal matrix, 70%-80% of diamond itself sticks out the body, thus the available working part is highly increased, the service life and efficiency is greatly improved accordingly.

Specification

ITEM	DIAMETER		INNER HOLE(MM)	HIGHT OF WORKING PART(MM)
ITEM	INCHES	MM	INNER HOLE(MM)	HIGHT OF WORKING PART(MM)
SDBD-04	4''	105	16,20,22.23	3/6
SDBD-43	4.3''	110	16,20,22.23	3/6
SDBD-45	4.5''	115	20,22.23	3/6
SDBD-05	5''	125	20,22.23	3/6
SDBD-06	6''	150	20,22.23	3/6
SDBD-07	7''	180	22.23,25.4,30	3/6
SDBD-08	8''	200	22.23,25.4,30	3/6
SDBD-09	9''	230	22.23,25.4,30,50	3/6
SDBD-10	10''	250	22.23,25.4,30,50	3/6
SDBD-12	12''	300	22.23,25.4,30,50	3/6
SDBD-14	14''	350	22.23,25.4,30,50	3/6
SDBD-16	16''	400	22.23,25.4,30,50	3/6

Remarks：

1. Slient cutting discs and sandwich segment can be offered.
2. Flange can be offered.
3. Other specifications can be customized.
